·Digital Storage Oscilloscope
·2 channels, 500 MHz bandwidth
·single shot 500 MS/s, repetitive 25 GS/s, 250 K/channel
·16 M RAM, 3.5" floppy disk, RS-232, GPIB.
The LeCroy LT342 oscilloscope is a graph-displaying device, it draws a graph of an electrical signal.
In most applications, the graph shows how signals change over time:
the vertical (Y) axis represents voltage and the horizontal (X) axis represents time.
The intensity or brightness of the display is sometimes called the Z axis.
The LeCroy LT342 oscilloscope's simple graph can tell you many things about a signal, such as:
the time and voltage values of a signal, the frequency of an oscillating signal,
the moving parts of a circuit represented by the signal, the frequency with
which a particular portion of the signal is occurring relative to, other portions,
whether or not a malfunctioning component is distorting the signal,
how much of a signal is direct current (DC) or alternating current (AC)
and how much of the signal is noise and whether the noise is changing with time.
