Performance
•Overall amplitude accuracy: 1.1 dB
•Third order intermodulation distortion: +7.5 dBm
Measurement Applications
•Narrow resolution bandwidth, 8590 series code compatibility, or 75 ohm tracking generator
•PowerSuite one-button power measurements included as standard
Features
•75 ohm input port (standard)
•75 ohm tracking generator and battery for field use (optional)
•5 minute warm-up to guaranteed measurement accuracy
•Rugged and portable for lab grade performance in the field
As the lowest cost ESA option, these basic analyzers are ideal for cost conscious bench-top or manufacturing environments.
Replacement solutions for the ESA-L:
Ideal low-cost solution, the N9000A CXA signal analyzer
Portable solution, the Handheld Spectrum Analyzers (HSA)
Lower cost alternative, the N9320B spectrum analyzer
