•Spectrum analysis with ultra-wide dynamic range
•Universal analysis of digital and analog modulated signals (option) such as BPSK, QPSK, π/4-DQPSK, 8PSK, QAM, MSK, GMSK, 2FSK, AM, FM, PM
•Refresh rate, quasi-analog 25 sweeps/s
•Large LC TFT display 24 cm/9.5", active
•Future-proof modular design Customized solutions through wide variety of options
•Displayed noise floor –150 dBm (typ.) in 10-Hz bandwidth
•3rd-order intercept point +20 dBm typ.
•1 dB compression point of RF input +10 dBm
•Sweep time: Span = 0 Hz - 1 µs to 2500 s in 5% steps; Span ≥10 Hz - 5 ms to 16 000 s in steps ≤10% ;Error limit<1%
•Sampling rate 50 ns (20 MHz A/D converter)
•Number of pixels 500
•AF demodulation types - AM and FM
